Mishimoto MK3 Focus RS intercooler pipe kit, 2016+

Description

Direct fit for the 2016+ Ford Focus RS
Silicone couplers absorb the stresses of excessive engine movement
Improves heat and pressure tolerance
46% and 45% less pressure drop than stock coldside and hotside pipe, respectively
31% and 40% increase in internal volume compared to stock coldside and hotside pipe, respectively
Both Mishimoto intercooler pipes and Mishimoto intercooler provide 35% less pressure drop than stock setup
Fits both stock and Mishimoto Focus RS intercooler
Designed to not block off cooling to the PTU
Mishimoto Lifetime Warranty

TECH SPECS
Installation Torque Specs27 in-lbs (3N*M) recommended for all t-bolt and constant tension t-bolt clamps. These clamps have an operating range of 18-35 in-lbs (2-4N*M). Do not exceed the maximum torque rating of 35 in-lbs (4N*M).

Silicone Couplers6

Purchase Includes(1) Hot-side Intercooler Pipe
(2) Silicone Couplers
(1) Wire-reinforced Silicone Hose
(6) T-bolt clamps
Mishimoto Lifetime Warranty

NoteFor optimal performance, the customer should retune the vehicle’s ECU after installing the Mishimoto cold-side intercooler pipe. Power gains will vary depending on the type of ECU tune that is applied to the vehicle, and other supporting modifications that are installed.

Constant Tension T-Bolt Clamps Specs(4) 76.2mm T-Bolt Clamps

Cold-Side Intercooler Pipe Specs63.5 mm-69 mm

Hot-Side Intercooler Pipe Specs63.5 mm

Engine Codes2.3L Ecoboost GTDi I4

Chassis CodesMKIII

Fits2016+ Ford Focus RS

CoatingPowder Coated

MakeFord
